FLIR E76 Advanced Thermal Imaging Camera

  • Sale
  • Regular price R 188,049.00
Tax included. Shipping calculated at checkout.

Please CONTACT US if you are interested in this product.



FLIR E76

Advanced Thermal Imaging Camera

The FLIR E76 offers complete coverage of near and distant targets through a range of interchangeable AutoCal™ lenses, with fields of view for everything from wide-angle roof inspections to electrical inspections performed from a safe distance. A step up from the FLIR E54, the E76 includes an optional temperature range to 1000°C (1832°F), laser-assisted autofocus, and 3 area measurement boxes. The 320 × 240 thermal resolution produces crisp, vibrant imagery that can be enhanced with patented FLIR MSX® technology for added detail and perspective. Onboard FLIR Inspection Route feature runs pre-planned survey routes to help inspectors stay organized when surveying large or multiple locations. For a limited time, the purchase of an E76 camera includes a 3-month subscription to FLIR Thermal Studio Pro and FLIR Route Creator.


INTERCHANGEABLE, AUTO-CALIBRATING LENSES

Telephoto, standard, and wide angle AutoCal™ lenses help users survey large targets quickly, check machines for signs of failure, or inspect electrical systems safely.

IMPROVED CONTRAST FOR FASTER DIAGNOSIS

Use FLIR 1-Touch Level/Span to instantly improve image contrast and highlight potential electrical or mechanical issues.

STREAMLINED REPORTING

Onboard integration with FLIR routing software*, a built-in mic for voice annotation, and report generation features all help the E76 streamline your workday.



Streamline Daily Surveys with Route Creation

Exx-Series cameras come equipped with FLIR Inspection Route. This camera mode guides users along a defined route across multiple locations and organizes images and data connected with each inspected asset. Users create a route in FLIR Thermal Studio Pro* with the Route Creator* plugin, then download it to the camera to streamline inspections and speed up post-processing and reporting. (*optional accessory software)

FLIR E76

Specifications

OVERVIEW

Display

4", 640 × 480 pixel touchscreen LCD with auto-rotation

Laser Pointer

Yes

Programmable Buttons

1

Text

Predefined list or touchscreen keyboard

Time Lapse

10 seconds to 24 hours (infrared)

Voice

60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth®

Weight & Dimensions (without lens)

1 kg (2.2 lbs), 278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in)

FLIR Screen-EST Mode

Yes

Sampling Average in Screen-EST Mode

Recommended temperature range: 30 to 45°C (86 to 113°F) in stable room temperature

FLIR Inspection Route

Enabled in camera

FLIR Care Logo
FLIR Protect Logo

Never Worry About Your Camera Performance Again

Keep your camera going strong with FLIR CARE and FLIR PROTECT. FLIR CARE provides world-class calibration with performance verification and traceable calibration adjustment services that ensure your thermal data is always accurate. FLIR PROTECT extended warranty and service packages provide a full three years of coverage beyond the respective camera’s factory warranty. FLIR PROTECT customers can also receive a bundled calibration service, discounts on additional services, and options for fast-delivered loaner cameras.

FLIR Care & Protect

Related Documents



Export Restrictions

The information contained in this page pertains to a dual use product controlled for export by the Export Administration Regulations (EAR). Diversion contrary to US law is prohibited. US Department of Commerce authorization is not required prior to export or transfer to foreign persons or parties unless otherwise prohibited.
