Guide TE211M Compact Handheld Thermal Imaging Monocular

Tax included. Shipping calculated at checkout.

Please CONTACT US if you are interested in this product.



Guide TE211M

Mini Handheld Thermal Imaging Monocular

The TE211M Mini Series handheld thermal imaging monocular is your compact night vision companion, featuring a 256×192 infrared detector and a 10mm lens with a detection range of up to 500 meters. Its 1.43” AMOLED full-color touchscreen delivers clear infrared images without needing to press your eyes against an eyepiece, minimizing eye strain during prolonged use. A quick 10-minute charge provides up to an hour of continuous operation, making it a reliable partner for your adventures.

Features:

  • 256x192 IR resolution
  • FOV 13.1°×13.1°
  • 500m Human Detection Range
  • Only 205g Ultra-Lightweight
  • IP67 Encapsulation



Advanced 12μm Detector for Exceptional Clarity

The TE211M features a cutting-edge 12μm detector, delivering sharp and detailed image quality that effortlessly highlights targets against their surroundings, even in complete darkness.

Ultra-Lightweight and Effortlessly Portable

Weighing just 200 grams, the TE211M boasts a sleek, pocket-sized design—smaller than a smartphone and thinner than a wristwatch. Its ergonomic grip and compact form ensure unparalleled ease of portability.

Innovative Large Touchscreen for Seamless Control

The TE211M is equipped with a groundbreaking large touchscreen, delivering ultra-clear visuals and intuitive touch functionality. Effortlessly swipe through menus and select features with simple touch gestures for a user-friendly experience.



Simplified Design for Intuitive Control

Designed with outdoor expertise in mind, the TE211M features a minimalist button and ring layout, allowing for smooth and straightforward menu navigation and function control.





Long-Lasting Battery with Rapid Charging

The TE211M is equipped with a built-in rechargeable battery, offering up to 6 hours of runtime. Its advanced 20W quick charge capability delivers an impressive 1 hour of use with just a 10-minute charge, ensuring reliable power whenever you need it.





Multimedia Capture with Ample Storage

AThe TE211M supports photos, videos, and audio recordings, ensuring a comprehensive way to document your adventures. With 16GB of built-in storage, you can easily capture and share unforgettable moments anytime, anywhere.

Enhanced Dual-Band WiFi for Superior Connectivity

The TE211M features upgraded dual-band WiFi, delivering stronger connections, faster data transmission, and extended range. Enjoy seamless upgrades in just 10 seconds and a maximum transmission distance of 26.5 meters for unmatched convenience.


Applications

Law Enforcement

Outdoor

Low Light Observation


Specifications

Sensor

Type

Uncooled VOx Infrared Detector, 8 to 14μm

Resolution

256×192@12μm

NETD

30mK

Frame rate

50Hz

Lens

Objective lens

10mm, F1.0

Field of view

13.1°×13.1°

FOV m@100m

23×23

Magnification

1.2x~4.8x

Detection range

500m/550yd

Focus

Focus-free

Display

Display type

Touch screen, 1.43'' AMOLED 466×466

Color palettes

White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia

Hardware

WIFI

2.4G, 5G

Interface

Monocular, exit pupil distance≥10 mm, diopter adjustment: -4 to+2

Others

Microphone, Bluetooth

System

Recording function

Photo/Video (Audio recording included)

Memory capacity

16GB

Power

Battery type

Built-in battery

Operating time

6 hours (Support 20W quick charging)

Environmental

Operating temp.

-20°C to 50°C / -4°F to +122°F

Encapsulation

IP67

Physical

Weight (g/oz)

205/7.23

Size (mm/in)

49×49×111/1.93×1.93×4.37

Standard

Device, Lens cover, Wrist strap, USB-A to USB-C Cable, Quick use guide, Safety Information Manual, Warranty card

Optional

Bluetooth remote control, Quick charging adapter, USB-C to USB-C Cable
