The AGM UNVG is a dual-channel night vision system. The UNVG uses advanced multi-coated optics and is built to last with a compact composite housing. The device can be outfitted with a Gen 2+ or Gen 3 high-performance image intensifier tube (IIT). The UNVG is also equipped with manual gain control, which adjusts the image brightness, providing the highest possible image quality even in changing light conditions. The independent movement of the tube pods allows for single or dual eye configurations for increased operational flexibility. Each tube automatically turns off when its pod is turned sideways. Operating from a single AA alkaline battery, the UNVG can run up to 15 hours. With an external battery pack (included), the operating time increases to 50 hours! Also equipped with an integral infrared illuminator for reading in the dark. The device can be installing to a either standard dovetail type headset and helmet mount.
AGM UNVG, Ultralight, Gen 2+ Green Phosphor NVG
Auto Off Feature: Each tube automatically turns off when its pod is turned sideways.
Quick Attachment Design: Dovetail base support for strong compatibility and durability.
Low Power Consumption Design: Utilizes single AA battery or external battery pack.
Corrosion and Impact-Resistant Housing: Matte black finish with PEEK+Glass fiber material for longevity.
Ultralight Housing: 17.6 oz / 500 g weight means improved mobility, responsiveness, and reduced fatigue.
IR Complement Function: Infrared illuminator for enhanced visibility in total darkness and close quarters environments.
Single/Double Eye Configuration: Pods independently adjustable for improved operational flexibility.
Independent Pod Movement: Pods can roll up and down for quick configuration changes.
Key Highlights
Clean Gen 2+ NL1 Optics
AGM’s NL1 tubes offer the highest resolution and cleanest image in the Gen 2+ range, with almost no visible spots in Zone 1.
Wide 40° Field of View
The 1x magnification and wide field of view give superior situational awareness without tunnel vision.
Hands-Free Night Vision
Includes soft headgear and Rhino mount for true hands-free use. Also compatible with helmet systems.
Rugged, Waterproof Build
Designed for extreme environments, with waterproof housing and simple, glove-friendly controls.
| SPECIFICATIONS | |
| Interpupillary Distance | Gen 2+ "Level 1" |
| Image Intensifier Tube | Gen 2+ "Level 1" |
| Resolution | 64-72 lp/mm |
| Field of view cleanness by zone | Gen 2 IIT AP is the highest resolution and the cleanest offered by AGM. There are practically no visible spots in Zone 1. |
| Magnification | 1x |
| Lens System | 25mm, F/1.23 |
| FOV | 40° |
| Focus Range | 0.25 m to Infinity |
| Eye Relief | 25 mm |
| Diopter Adjustment | -6 to +2 diopters |
| Infrared Illuminator | Yes |
| Manual Gain Control | Yes |
| Battery Type | One AA (1.5 V) or External Battery Pack (four AA or two CR123A) |
| Battery Life (Operating) | One AA - up to 15 hours / External Battery Pack (four AA) - up to 50 hours / External Battery Pack (two CR123A) - up to 30 hours |
| Exit Pupil Diameter | 14 mm |
| Operating Temperature Range | -40°C to +50°C (-40°F to +122°F) |
| Storage Temperature Range | -50°C to +70°C (-58°F to +158°F) |
| Weight | (w/o battery) - Goggles: 500 g (1.1 lb) / External Battery Pack: 250 g (0.55 lb) |
| Overall Dimensions | Goggles: 101 × 116 × 85 mm (4.0 × 4.6 × 3.3 in) / External Battery Pack: 102 × 86 × 34 mm (4.0 × 3.4 × 1.3 in) |
| Package Includes | Night Vision Goggles, External Battery Pack, Connecting Cable with Battery Adapter, Demist Shield (2), Sacrificial Window (2), Neck Strap, Carrying Case, Lens Cloth, User Manual, AA Battery |
| Protection Level | IP67 |
EXPORT NOTICE
This product is subject to US export regulations and may require a license prior to export. Any diversion contrary to US law is prohibited.
