AGM NVM-50 NW1

Tax included. Shipping calculated at checkout.

Please CONTACT US if you are interested in this product.



AGM NVM-50 NW1 NIGHT VISION MONOCULARS

Description

The NVM-50 is the standard by which all compact multi-use monoculars should be judged, now and in the future. The NVM-50 employs optics that are equal or superior to current Military-issue night vision devices, built into a rugged, compact, and ergonomic composite housing. We built this device to exceed user expectations and MIL-SPEC-810 specifications; as a result, the NVM-50 offers unmatched performance even in rain, salt water, temperature extremes, and high-humidity environments. Its 51° field of view (FOV) covers a large visual range, without requiring the operator to shift the position of the device. The NVM-50 is available with a vast array of accessories, including 3x and 5x magnification lenses for mid to long-range viewing; head or helmet mounts to enable handsfree operation; and, a detachable IR illuminator for long-range use.

Features

  • Wide 51° field of view
  • Compact, sturdy design
  • Head- or helmet-mountable for hands-free usage
  • Bright light cut-off system
  • Ergonomic, simple, easy-to-operate controls
  • Utilizes a single CR123A Lithium or AA battery
  • Built-in Infrared illuminator and flood lens
  • Limited 3-year warranty

Characteristics:

Image Intensifier Tube: Gen 2+ "White Phosphor" "Level 1"

Magnification: 1x (3x and 5x optional)

Lens System: 19 mm; F/1.26

FOV: 51°

Package Includes:

- Night Vision Monocular

- Lens Cloth

- Soft Carrying Case

- Manual

Specifications:

Image Intensifier Tube

Gen 2+ "White Phosphor Level 1"

Resolution

51-64 lp/mm

Field of view cleanness by zone

Gen 2 IIT NL1 is the highest resolution and the cleanest offered by AGM. There are practically no visible spots in Zone 1.

Magnification

1x (3x and 5x optional)

Lens System

19 mm; F/1.26

FOV

51°

Focus Range

0.25 m to Infinity

Eye Relief

17 mm

Led Indicators

- Low Battery - IR On - Excessive Light Conditions

Automatic Brightness Control

Yes

Bright Light Cut-Off

Yes

Automatic Shut-Off System

Yes; Two power levels

Battery Type

One CR123A (3V) or AA (1.5 V)

Battery Life (Operating)

Up to 40 hours at 20°C

Operating Temperature Range

-40°C to +50°C (-40°F to +122°F)

Storage Temperature Range

-50°C to +50°C (-58°F to +122°F)

Weight

0.34 kg (0.75 lbs)

Overall Dimensions

110 × 49 × 73 mm (4.3 × 1.9 × 2.8 in)

Package Includes

Night Vision Monocular, Lens Cloth, Soft Carrying Case, Manual
